The HAMM HD 12 VV Double Drum Vibratory Roller: An Overview

HAMM HD 12 VV: Key Features

• Simple transport, simple loading

• Simple, intuitive and language-neutral control

• Ergonomic driver platform

• Excellent view of drum edge, machine and construction site environment

• Compact dimensions

HAMM HD 12 VV: Specs

Basic data

Series: HD CompactLine
Name: HD 12 VV
Description: Tandem roller with two vibrating roller drums
Exhaust emissions category: EU Stage V / EPA Tier 4
Series: H230

Weights

French classification, value/class: 11,3/PV3
Max. operating weight: 7,519 lbs
Operating weight with ROPS: 5,942 lbs
Static linear load, rear: 63.3
Static linear load, front: 62.2 lbs/in

Machine dimensions

Total width: 51.6 in
Total length: 99.6 in
Maximum working width: 49.2 in
Center distance: 66.9 in
Ground clearance, center: 11 in
Turning radius, inside: 93.3 in
Total height with ROPS: 97.4 in
Height loading, min.: 69 in
Curb clearance, rear: 22.4 in
Curb clearance, left: 22.4 in

Drum dimensions

Drum type, front: Smooth/non-split
Drum type, rear: Smooth/non-split
Track offset, right: 2 in
Track offset, left: 0 in
Drum thickness, rear: 0.6 in
Drum thickness, front: 0.6 in
Drum diameter, rear: 28.3 in
Drum diameter, front: 28.3 in
Drum width, rear: 47.2 in
Drum width, front: 47.2 in

Diesel engine

Model: D1703
Cylinders, quantity: 3
Exhaust emission standard: EU Stage V / EPA Tier 4
Exhaust gas after-treatment: -
Power ISO 14396, rpm: 2,200 rpm
Power ISO 14396, HP: 25.2 HP
Power ISO 14396, kW: 18.5 kW
Power SAE J1349, rpm: 2,200 rpm
Power SAE J1349, HP: 24.8 hp
Power SAE J1349, kW: 18.5 kW

Travel drive

Speed, infinitely variable: 6.3
Climbing ability, without vibration: 40 %
Climbing ability, with vibration: 30

Vibration

Centrifugal force, rear, II: 5,175 lbs
Centrifugal force, rear, I: 8,550 lbs
Centrifugal force, front, II: 5,175 lbs
Centrifugal force, front, I: 8,550 lbs
Amplitude, front, II: 0.018 in
Amplitude, front, I: 0.018 in
Vibration frequency, rear, II: 3,060 VPM
Vibration frequency, rear, I: 3,900 VPM
Vibration frequency, front, II: 3,060 VPM
Vibration frequency, front, I: 3,900 VPM
Amplitude, rear, II: 0.018 in
Amplitude, rear, I: 0.018 in

Steering

Steering, type: Articulated steering
Oscillation angle +/-: 8 °

Water-sprinkling system

Water sprinkling, type: Pressure
Fuel tank, capacity: 11.1 gal
Water tank, capacity: 47.6 gal

Tank capacity/filling capacity

Fuel tank, capacity: 11.1 gal
Water tank, capacity: 47.6 gal

Sound level

Acoustic power LW(A), measured: 104 db(A)
Sound power level L(WA), guaranteed: 106

Common Uses

The HAMM HD 12 VV Double Drum Vibratory Roller is most commonly used for paving roads and driveways, compacting soil and asphalt, and creating a smooth and even finish on surfaces. It can also be used for a variety of other construction projects, including trenching, backfilling, and landscaping. The HAMM HD 12 VV Double Drum Vibratory Roller is a powerful and reliable machine that can handle a variety of tasks with ease.

Price and Rental Information

The HAMM HD 12 VV Double Drum Vibratory Roller has a purchase price of $44,900. If you need to rent the machine for a day, the cost is $275. The cost to rent it for a half day is $138, and the cost to rent it for a week is $800. The estimated monthly maintenance costs for this machine are approximately $200.

Similar Models

If you are looking for a machine similar to the HAMM HD 12 VV Double Drum Vibratory Roller, there are several other models available. Some of these include the Caterpillar CS-533E Vibratory Roller, the Dynapac CC1200 Vibratory Roller, the Dynapac CA1300D Vibratory Roller, the HMM 3307 Vibratory Roller, and the Bomag BW11RH-2 Vibratory Roller.

Conclusion

In this article we detailed the HAMM HD12VV specs, dimensions, and costs. The HAMM HD 12 VV Double Drum Vibratory Roller is a powerful and reliable machine that is perfect for a wide range of construction projects. It comes with an ergonomic driver platform, ensure you get both power and comfort. It has a purchase price of $44,900 and can be rented for a day, half day, or week. The machine has an operating weight of 3410 pounds and estimated monthly maintenance costs of $200. You can find several machines similar to this HAMM model, including the Caterpillar CS-533E Vibratory Roller, the Dynapac CA1300D Vibratory Roller, and the Bomag BW11RH-2 Vibratory Roller.
