Komatsu PC210LC-11 Specs: A Closer Look

Boom/Stick Option (Hex) 1

Shipping Length Of Unit - 31.3ft in

Shipping Height Of Unit - 9.79ft in

Max Cutting Height - 31.17ft in

Max Loading Height - 21.76ft in

Max Reach Along Ground - 28.42ft in

Max Vertical Wall Digging Depth - 15.2ft in

Max Digging Depth - 17.66ft in

Boom/Stick Option (Hex) 1 - Monoboom w/ stick 1800mm

Boom/Stick Option (Hex) 2

Shipping Length Of Unit - 31.35ft in

Max Cutting Height - 32.16ft in

Shipping Height Of Unit - 10.46ft in

Max Loading Height - 22.61ft in

Max Reach Along Ground - 30.16ft in

Max Vertical Wall Digging Depth - 17.82ft in

Max Digging Depth - 20ft in

Boom/Stick Option (Hex) 2 - Monoboom w/ stick 2400mm

Boom/Stick Option (Hex) 3

Shipping Length Of Unit - 31.12ft in

Max Cutting Height - 32.81ft in

Max Loading Height - 23.33ft in

Shipping Height Of Unit - 9.74ft in

Max Reach Along Ground - 31.83ft in

Max Vertical Wall Digging Depth - 19.62ft in

Max Digging Depth - 21.72ft in

Boom/Stick Option (Hex) 3 - Monoboom w/ stick 2900mm

Boom/Stick Option (Hex) 4

Shipping Length Of Unit - 32.6ft in

Shipping Height Of Unit - 10.65ft in

Max Cutting Height - 33.14ft in

Max Loading Height - 23.58ft in

Max Reach Along Ground - 29.63ft in

Max Digging Depth - 16.67ft in

Boom/Stick Option (Hex) 4 - Two piece boom w/ stick 1800mm

Max Vertical Wall Dig Depth - 13.52ft in

Boom/Stick Option (Hex) 5

Shipping Length Of Unit - 32.12ft in

Shipping Height Of Unit - 11.51ft in

Max Cutting Height - 34.34ft in

Max Loading Height - 24.63ft in

Max Reach Along Ground - 31.47ft in

Max Digging Depth - 18.66ft in

Boom/Stick Option (Hex) 5 - two piece boom w/ stick 2400mm

Max Vertical Wall Dig Depth - 16.33ft in

Boom/Stick Option (Hex) 6

Max Cutting Height - 35.47ft in

Max Loading Height - 25.84ft in

Shipping Length Of Unit - 32.07ft in

Max Reach Along Ground - 33.13ft in

Shipping Height Of Unit - 11.43ft in

Max Digging Depth - 20.35ft in

Boom/Stick Option (Hex) 6 - two piece bomo w/ stick 2900mm

Max Vertical Wall Dig Depth - 17.44ft in

Dimensions

Ground Clearance - 1.45ft in

Height To Top Of Cab - 9.9ft in

Width To Outside Of Tracks - 8.86ft in

Length Of Track On Ground - 10.73ft in

Tail Swing Radius - 9.19ft in

Removal Counterweight Clearance - 3.61ft in

Undercarriage

Track Gauge - 7.22ft in

Shoe Size - 19.69in

Ground Pressure - 8.1psi

Max Travel Speed - 3.42mph

Drawbar Pull - 40124lb

Number Of Track Rollers Per Side - 7

Number Of Shoes Per Side - 45

Number Of Carrier Rollers Per Side - 2

Engine

Number Of Cylinders - 6

Engine Make - 2238

Engine Model - SAA6D102E-2

Net Power - 143hp

Power Measured @ - 1950rpm

Displacement - 358.9cu in

Aspiration - Turbocharged, after-cooled

Operational

Operating Weight - 44632.6lb

Fuel Capacity - 105.7gal

Cooling System Fluid Capacity - 8.2gal

Hydraulic System Fluid Capacity - 37.8gal

Engine Oil Capacity - 6.4gal

Operating Voltage - 24V

Swing Drive Fluid Capacity - 1.8gal

Alternator Supplied Amperage - 60amps

Hydraulic System Relief Valve Pressure - 5404.9psi

Hydraulic Pump Flow Capacity - 113.1gal/min

Swing Mechanism

Swing Speed - 12.4rpm

Buckets

Reference Bucket Capacity - 1.3yd3

Common Uses

The Komatsu PC210 LC-11 is a versatile machine that can be used for a variety of applications. It's commonly used for excavating, trenching, grading, and loading operations. It can also be used for demolition, earthmoving, and material handling. The machine is also suitable for lifting and transporting heavy materials.

Price and Rental Rates

The Komatsu PC210 LC-11 has an MSRP of $234,640.24. It can be rented for a day for $1,095, for a half-day for $548, or for a week for $2,995.

Operating Weight and Maintenance Costs

The Komatsu PC210 LC-11 has an operating weight of 53,882 lbs. It's important to note that the estimated monthly maintenance costs for this machine can vary depending on the type of work being done. Generally, the estimated monthly maintenance costs are around $500.

Fuel Costs

The estimated fuel cost per month for the Komatsu PC210 LC-11 is approximately $1,500. The estimated hourly fuel cost for this machine is $3.50 per hour.

Similar Models

The Komatsu PC210 LC-11 is a powerful and reliable machine that is well-suited for many heavy-duty operations. If you are looking for similar models, you may want to consider the Komatsu PC220-8, the Komatsu PC228USLC-11, or the Komatsu PC290LC-10.

Conclusion

The Komatsu PC210 LC-11 is a powerful and reliable excavator that is well-suited for a variety of applications. It's equipped with a high-performance engine and advanced hydraulic systems that allow for precise and accurate control. It also has a large operator cab that provides a comfortable and safe working environment. The machine has an MSRP of $234,640.24 and can be rented for a day, a half-day, or a week. The estimated monthly maintenance costs for this machine are around $500, and the estimated fuel cost per month is approximately $1,500. If you are looking for similar models, you may want to consider the Komatsu PC220-8, the Komatsu PC228USLC-11, or the Komatsu PC290LC-10.
