1991 Link-Belt ATC822
- 5544 miles
- Ships nationwide
- #A5001243
249
+246 more1991 Link-Belt ATC822 20 ton 4x4x4 4x4x4 All Terrain Crane
- 5544 miles
- Ships nationwide
- #A5001243
No longer available
IronClad Assurance
Inspected by IronPlanet. Your purchase is protected by our IronClad Assurance.
About this equipment
1991 Link-Belt ATC822 20 ton 4x4x4 4x4x4 All Terrain Crane Hours and condition are captured at the time of listing and are subject to change. Please contact a representative about this piece of equipment for an updated reading.
Features
AI-Generated: Verify machine specs, features, and operability prior to purchasing.
6 Speed Automatic Transmission
1348 hrs Carrier Engine
Cummins 6 Cylinder Diesel Carrier Engine
Microguard 414 Load Moment Indicator
27 ft Minimum 70 ft Maximum Boom Length
Auxiliary Hoist
Rooster Sheave
21 ft to 43 ft Bifold Swingaway Offset Jib
564 lb 3 Sheave Hook Block
Overhaul Ball
Specifications
AI-Generated: Verify machine specs, features, and operability prior to purchasing.
Engine Power: 131 hp
Displacement: 276 cu in
Maximum Lift Capacity: 22 tons
Boom Length: 70 ft
Jib Length: 43 ft
Drive Type: 4x4
Maximum Travel Speed: 20 mph
Counterweight: 7500 lbs
Operating Weight: 48000 lbs
Serial Number / VIN: 71I1-0474
Hour Meter / Odometer: 5544 mi
Exterior Lights: Operational
Safety Certification Label: There is a safety certification label with a date of 1/14/16
Safety Certification Report: Safety Certification Report Available
Load Chart: Yes
Travel Alarm: Inoperable
Horn: Missing
Seat Belts: Not equipped
Safety Lock Out/Stop: Operational
Current Safety Manual: Yes
Current Operator/Maintenance Manual: Yes
Lower/Carrier Engine Hours: 1348 hrs Carrier Engine
Window Controls: Operational
Seat Belts: Operational
Horn: Electric Horn Inoperable
Engine Oil Pressure: The gauge registers in the operating range.
Warning Lights: Operational
Gauges: Operational
Clutch: Engages
PTO Control: Cable engaged, Operational
Heater: Not operationally checked
Limited Function Check: The main components are in place and operational as noted.
Emissions Status: No US EPA Label Present
Blow-by (subjective visual observation): No noticeable vapor or pressure
Starter: Operational
Air Compressor: Operational
Fuel System: Operational
Oil Leaks: No dripping leaks
Fuel Leaks: No dripping leaks
Cooling System Leaks: No dripping leaks
Limited Function Check: The engine started and ran.
Transmission: Operational
Limited Function Check - Carrier: The drivetrain was operational without a load.
Brake Type: Air
Limited Function Check - Brakes: The brake system functioned, stopping and holding the machine.
Hydraulic Tank: Dripping leak
Limited Function Check: The hydraulic system was operational.
Mirrors: No visible damage or missing components
Load Moment Indicator: Powers On, Not operationally checked
Anti Two Block: Not operationally checked
Oil Pressure: The gauge registers in the operating range.
Drum Rotation Indicator: Operational
Limited Function Check (Engine): The engine started and ran.
Limited Function Check: The main crane components functioned when checked without a load.
Digital Glovebox
For your convenience, we've included these documents free to download so you can make the best decision.
Close-up detailed photos
Inspection Report
Listings may picture specialty attachments not included in the sale. If you have questions about machine configuration, contact our sales team.
