2020 Caterpillar 249D3

  • 2566 hours
  • Ships nationwide
  • USA
  • #A2088567
88
image+85 more

2020 Cat 249D3 Two-Speed Compact Track Loader

  • 2566 hours
  • Ships nationwide
  • United States
  • #A2088567
Asking Price$22,000 USD
Est. Loan Payment

Price excludes taxes, fees, and shipping

  • IronClad Assurance

    IronClad Assurance

    Inspected by IronPlanet. Your purchase is protected by our IronClad Assurance.

  • No Payments For 90 Days

    Buy now, pay later for well qualified borrowers. Don't let heavy cost slow you down.

About this equipment

The 2020 Caterpillar 249D3 is a compact track loader designed to offer versatility and performance in demanding environments. This model features a robust 72-inch bucket, ideal for a wide range of loading and material handling tasks. With 12-inch track belts, it provides enhanced stability and reduced ground pressure, allowing it to operate effectively on soft, muddy, or sensitive surfaces. The open operator station coupled with joystick steering enhances operator comfort and machine maneuverability, making it a practical choice for extended use in varied conditions. Additionally, the machine includes a manual quick coupler that simplifies the process of switching attachments, and a counterweight kit to improve its lifting capabilities. With 2566 hours of operation, this Caterpillar 249D3 is ready to contribute to your project needs efficiently.

Listings may picture attachments not included in the sale. Contact our sales team to confirm features, specs, and machine configuration.

Features

  • Open Operator Station

  • Joystick Steering

  • 12 in Track Belts

  • Manual Quick Coupler

  • 72 in Bucket

  • Counterweight Kit

Specifications

  • Engine Power: 67.1 hp

  • Displacement: 203.2 cu in

  • Operating Weight: 8,945 lbs

  • Fuel Capacity: 24.6 gal

  • Track Width: 15.7 in

  • Ground Pressure: 4.9 psi

  • Rated Operating Capacity: 2,125 lbs

  • Tipping Load: 6,070 lbs

  • Max Travel Speed: 8 mph

  • Hydraulic Flow - Standard: 20 gal/min

  • Hydraulic Pressure: 3335 psi

  • Length of Track on Ground: 59 in

  • Serial Number / VIN: CAT0249DPP9C00780

  • Hour Meter / Odometer: 2566 hrs

  • Exterior Lights: Operational

  • Travel Alarm: Operational

  • Horn: Operational

  • Seat Belts: Operational

  • Safety Lock Out/Stop: Operational

  • Current Safety Manual: Yes

  • Current Operator/Maintenance Manual: Yes

  • Warning Lights: Operational

  • Gauges: Operational

  • Limited Function Check: The main components are in place and operational as noted.

  • Engine: No US EPA Label Present

  • Blow-by (subjective visual observation): Minor

  • Starter: Operational

  • Oil Leaks: No dripping leaks

  • Fuel Leaks: No dripping leaks

  • Cooling System Leaks: No dripping leaks

  • Limited Function Check: The engine started and ran.

  • Limited Function Check: The drivetrain was operational.

  • Auxiliary Hydraulic Plumbing: Not operationally checked

  • Limited Function Check: The hydraulic system was operational.

  • Limited Function Check: The main chassis components were operational in a limited check.

  • Grouser Height Measurement : Left side: 21 mm, Right side: 21 mm

  • Track Belt Condition: No visible damage

  • Rubber Belt Drive Lugs: No visible damage

  • Track Tensioners: Operational, No visible damage

  • Quick Coupler: Not operationally checked

  • Loader Bucket Cutting Edge/Shanks/Teeth: One tooth missing others are worn
