Advanced Power Train with Lock-Up Clutch
Next Generation Electro-Hydraulic Controls
Premium Cabin with HVAC and Sound Suppression
Heated and Ventilated Suspension Seat (Optional)
Multifunctional Touchscreen Display with Integrated Backup Camera
Programmable Kick-Outs for Bucket and Boom Positioning
Ride Control System for Improved Ride Quality
Efficient Load-Sensing Hydraulics with Variable Displacement Pumps
Auto-Idle and Auto-Shutdown for Fuel Efficiency
High Intensity Discharge (HID) and LED Work Lights for Night Operations
Fender Guard Kit for Wheel Protection (Optional)
360-Degree Proximity Detection and Visibility System (Optional)
Automatic Greasing System for Reduced Maintenance
Dual-Mode Steering for Precision or Conventional Operation
Remote Monitoring Capability with Cat Product Link
Engine Power: 230 hp
Net Power - ISO 9249: 230 hp
Peak Torque at 1,400 rpm: 878 lb ft
Displacement: 427.8 cu in
Bucket Capacity: 3.3-4.4 yd³
Operating Weight: 42,357 lb
Breakout Force: 32,696 lb
Static Tipping Load - Full Turn: 26,674 lb
Maximum Hinge Pin Height: 13.5 ft
Dump Clearance at Max Raise: 9.5 ft
Transmission Type: Countershaft Powershift
Forward Speeds: 4
Reverse Speeds: 4
Fuel Tank Capacity: 77.9 gal
Hydraulic System Fluid Capacity: 44 gal
