JLG G5-18A: Overview

The G5-18A: Key Features

Comfortable cab to reduce operator fatigue

Tight turning radius to maneuver through crowded jobsites

Fuel-efficient Tier 4 final Deutz engine

Variety of attachments for versatility in handling jobsite challenges

Universal skid steer adapter compatible with existing skid steer attachments

Standard LED Motion/Amber Beacon with ClearSky Smart Fleet™ Connectivity Hardware

The G5-18A Specs

Performance

Breakout Force: 8900 lb / 4036.97 kg

Drawbar Pull: 8700 lb / 3946.25 kg

Lift Capacity at Full Height: 4400 lb / 1995.81 kg

Lift Capacity at Max Reach: 1850 lb / 839.15 kg

Load Center: 2 ft / 0.61 m

Maximum Lift Capacity: 5500 lb / 2494.76 kg

Maximum Lift Height: 18 ft 4 in. / 5.59 m

Maximum Reach: 10 ft 11 in. / 3.33 m

Outriggers or Stabilizers: No

Outside Turning Radius: 10 ft 7 in. / 3.23 m

Speed - Maximum Crowd: 2 sec.

Speed - Maximum Dump: 2.5 sec.

Speed - Maximum Lift: 6.8 sec.

Speed - Maximum Lower: 4.6 sec.

Speed - Maximum Telescope In: 3.8 sec.

Speed - Maximum Telescope Out: 6.7 sec.

Speed - Maximum Travel: 15 mph / 24.14 km/h

Towing Capacity: 6600 lb / 2993.71 kg

Dimensional Data

Ground Clearance: 11 in. / 0.27 m

Machine Height: 6 ft 4 in. / 1.92 m

Machine Length: 10 ft 9 in. / 3.28 m

Machine Length (Forks): 12 ft 6 in. / 3.82 m

Machine Width: 6 ft / 1.82 m

Tire Size: 12x16.5 Pneu

Wheelbase: 7 ft 6 in. / 2.29 m

Power Source

Capacity - Coolant: 3.5 gal. / 13.25 L

Capacity - Engine Oil: 9.1 gal. / 34.45 L

Capacity - Fuel Tank: 24 gal. / 90.85 L

Engine Horsepower: 74 hp / 55.20 kW

Engine Manufacturer Deutz

Engine Model TD 2.9L L4 T4F

Maximum Engine RPM 1800 rpm

General

Axle-Front High Bias, Limited Slip

Axle-Rear Planetary

Capacity - Hydraulic Reservoir 16 gal. / 60.57 L

Function Pump Type Gear

Hydraulic System Flow 19.1 gal/min. / 72.29 L/Min

Hydraulic System Pressure 3500 psi / 245.11 Kg/cm2

Operating Vehicle Weight 11000 lb / 4989.52 kg

Service Brake Type Wet Multi-Disc

Transmission - Nr Forward Gears Standard 1

Transmission - Nr Reverse Gears 1

Transmission Type Hydrostatic

Common Uses

The G5-18A is a popular choice for a variety of applications, including construction, maintenance, and repair work. It can be used to reach heights that would be difficult or impossible to reach with a ladder. It is also great for painting, window washing, and other tasks that require a stable platform. Its 500 lb load capacity makes it ideal for lifting materials, tools, and equipment.

Pricing

The JLG G5-18A has an MSRP of $111,493. The price to rent it for a day is $315, for a half day is $158, and for a week is $785.

Maintenance and Fuel Costs

The estimated monthly maintenance costs for the JLG G5-18A is $400. The estimated fuel cost per month is $400, and the estimated hourly fuel cost is $20.

Similar Models

If you are looking for models similar to the JLG G5-18A, you might want to consider the Genie GS-2632, the JLG G6-42A, and the Skyjack SJIII 3219. Each offers similar features and capabilities to the G5-18A but may vary in price and performance. You might want to consider these smart models Genie G9-43A and JLG G12-55A.

Conclusion

The JLG G5-18A is a powerful and reliable aerial lift that is perfect for a variety of applications. It has a maximum platform height of 18 feet and a maximum working height of 24 feet. It has a maximum load capacity of 500 lbs, and an operating weight of 10,800 lbs. It is powered by a dual fuel engine, allowing it to run on either gasoline or diesel. The G5-18A is an ideal choice for anyone looking for an aerial lift that is both reliable and cost-effective.

Featuring a variety of attachments for versatility, the G5-18A makes even the toughest jobsite challenges a breeze. But the G5-18A is not only powerful. It also features a comfortable cab that eliminates operator fatigue. So with the G5-18A, you'll be able to comfortably maneuver through crowded terrain and handle any task.

If you are looking for similar models, you might want to consider the Genie GS-2632, the JLG G6-42A, and the Skyjack SJIII 3219.
