Used Articulated Trucks for sale

-

5 results found

  • 2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale2023 Ausa DR-1001-AHG- for sale

    2021 Ausa DR1001 AHG Dumper

    4 Hours

    $105,450

    Ships nationwide
    Quick View
    2023 Ausa DR-1001-AHG- for sale

    2021 Ausa DR1001 AHG Dumper

    $105,450

    About this equipment

    The DR1001AHG reversible dumper has a 10,000 kg (22,000 lb) payload and comfortable hydrostatic transmission. Thanks to the innovative reversible design, the seat can rotate 180 degrees and all components are instantly adjusted to suit the driver's new position: steering wheel, joystick, pedals, safety cameras, etc. The driver can also comfortably and safely get on and off both sides of the dumper, so speed and flexibility are significantly increased. In terms of technology, various systems have been included to make it a more efficient dumper: it has the ECO Mode function, where the engine speed is automatically controlled to ensure lower fuel consumption and CO2 emissions. It is fitted with the Hill Holder system, a start-assist and safety system that engages the dumper's brake when you take your foot off the accelerator at zero speed. This significantly increases safety, especially when operating on slopes. It can also be equipped with Smart Stop: a plug-in system that automatically shuts down the engine when it is not in use and the optimal time and safety requirements are met.

    Features

    • 22,000 lb load capacity
    • Max. speed: 13.7 mph
    • Max. gradient: 45%
    • External turning radius: 247 in

    Specifications

    • Level hopper capacity: 4.32 cu yd
    • Heaped hopper capacity: 5.10 cu yd
    • Engine: DEUTZ, TCD3.6 L4 HT, 74.3 hp, 2,200 rpm, 405@1300 N·m@rpm, 4 cylinders, Tier 4 Emissions
    • Hydraulic System: Hydraulic circuit double gear pump, 13.2 gal/min, 2,611 psi
  • Warranty available

    2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale2023 Ausa D150AHG for sale

    2022 Ausa D150 AHG Dumper

    4 Hours

    $34,995

    $37,609

    Ships nationwide
    Quick View
    2023 Ausa D150AHG for sale

    2022 Ausa D150 AHG Dumper

    Warranty available

    $37,609

    $34,995

    About this equipment

    The D150AHG is part of the most compact range of articulated dumpers, with a 1.5-tonne (3,300 lb) payload and a 180-degree swing skip, it has a perfect payload size ratio. The small size of the D150AHG, makes it suitable for minor construction work and work in difficult-to-reach areas such as narrow streets and parks and, with its swing skip, it is perfect for filling ditches. Its permanent 4x4 drive allow it to handle the toughest terrains. With its hydrostatic transmission, maximum comfort and safety are assured. Thanks to the transmission brake, it prevents the machine from moving under its own weight on slopes, without you even touching the brake pedal. Also, as there is no need to change gears, the driver can focus on the movements of the machine and its load.

    Features

    • Max. speed: 8.7 mph
    • Maximum gradient: 40%
    • External turning radius: 128.3in
    • 4WD

    Specifications

    • Load Capacity: 3,300 lb
    • Chassis: Articulated and oscillating
    • Water hopper capacity: 0.68 cu yd
    • Level hopper capacity: 0.82 cu yd
    • Heaped hopper capacity: 1.18 cu yd
    • Transmission: Hydrostatic
    • Engine: KUBOTA, D1105-E4B, 20.9 hp, 2400 rpm, 71.4@1600 Nm@rpm, 3 cylinders,
    • Emissions: EPA Tier4, Stage V
    • Hydraulic System: Main pump 0.49 cc gear pump, Flow rate 4.56 gal/min, Working pressure 180 bar
  • 2004 Volvo A25D for sale2004 Volvo A25D for sale2004 Volvo A25D for sale2004 Volvo A25D for sale2004 Volvo A25D for sale2004 Volvo A25D for sale2004 Volvo A25D for sale2004 Volvo A25D for sale

    2004 Volvo A25D

    11,507 Hours

    $111,995

    Ships nationwide
    Quick View
    2004 Volvo A25D for sale

    2004 Volvo A25D

    $68,995

    $111,995

    Features

    • PTO
    • Differential Lock
    • Equipped With DEF Tank
    • A/C & Heat
    • Radio

    Specifications

    • Engine: Volvo D9AAEE2 - 6 Cyl - 287 HP - Diesel
    • EPA Tier 2
    • 6 FWD + 2 REV Automatic Transmission
    • 6x6
    • Air Brakes
    • Payload Capacity: 24 tons
    • Body Volume: 18.3 cubic meters
    • Maximum Speed: 33 mph
    • Turning Radius: 23.3'
    • Tire Size: Triangle 23.5R25
    • Wheelbase: 14'
    • Operating Weight: 51,147 lbs
  • 2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale2019 Caterpillar 745 for sale

    2019 Caterpillar 745

    9,127 Hours

    $380,000

    Quick View
    2019 Caterpillar 745 for sale

    2019 Caterpillar 745

    $380,000

    Features

    • Auto Traction Control
    • Heated Bed
    • Product Link
    • Bed, Standard
    • Liner, Steel Bed
    • Erops
    • Supp Steer
    • Engine Brake
    • Tailgate
    • Rear View Camera
    • Cycle Counter
    • Bed Liner
    • Bluetooth Radio
    • Air Conditioning
    • Am/fm Radio
    • Differential Lock/unlock
    • Cat 745 Articulated Truck
    • Air Suspensions Seat
  • 2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale2018 Caterpillar 745 for sale

    2018 Caterpillar 745

    5,774 Hours

    $422,000

    Quick View
    2018 Caterpillar 745 for sale

    2018 Caterpillar 745

    $422,000

    Features

    • Auto Traction Control
    • Product Link
    • Erops
    • Supp Steer
    • Engine Brake
    • Tailgate
    • Air Conditioning
    • Air Suspension Seat
    • Am/fm Radio
    • Rear View Camera
    • Cycle Counter
    • Bluetooth Radio
    • Differential Lock/unlock
    • Cat 745 Articulated Truck

Get access to our latest deals

Overview

An articulated truck is a heavy-duty dump truck used to transport heavy loads. The all-wheel-drive capability makes articulated trucks a great option for transporting loads over rough terrains. The name “articulated” comes from the cab and rear dump meeting at an articulated point, controlling the capability of the truck to pivot. On the other hand, rigid dump trucks, have a chassis comprised of one continuous piece of metal. Articulated trucks are mainly used as soil and aggregate dumpers, but the chassis can facilitate many other applications including mining, construction, and even military. If you need to maneuver over rugged and sometimes tight terrains, you need an articulated truck.

Frequently Asked Questions

  • The price of used articulated trucks depends on the model, make, and year. You can find used articulated trucks from $20,000 for early 2000’s models up to $500,000 for a lightly used newer model.

  • Popular brands of used articulated trucks include Caterpillar, John Deere, Volvo, and Komatsu Limited.

  • Articulated trucks transport heavy loads like soil, aggregate, and water across rugged and hard-to-maneuver terrains.

  • Articulated trucks weigh around 50,000 lbs with an operating rate of up to 165,000 pounds. Most articulated trucks have an operating weight of at least double their empty weight.

  • Articulated trucks rotate at an articulated joint forming a 90-degree angle with the bed joint. Articulated trucks have manual and automatic traction control, retarder control, and dump systems. Always refer to the operator's manual when running new equipment.

  • When buying an articulated truck, it’s important to conduct a full safety inspection. Things to look for include loose fittings, leaks, tire damage, fluid levels, and brake wear.

  • How a used articulated truck compares to a newer model depends on how many hours it's logged and how recently components showing wear were replaced. High wear areas include the hinge joints, brakes, and the engine block.

  • Articulated truck drivers make between $15 and $30/hour.

  • Requirements to become an articulated truck operator vary from state to state, but they may include: At least 20/40 vision with glasses or corrective lenses. A 70-degree field of vision in each eye. A valid driver’s license. Working knowledge of safe operation and vehicle inspection.
